Socata Rallye MS-893A

Detta är vårt bogserflygplan

SF-25C SE-UBK

Privatägd men får disponeras av klubben

Data:

Aspect ratio 13.4

Span 15.53 m

Area 14.47 sq.m

Empty Weight 335 kg

Payload 195 kg

Gross Weight 530 kg

Wing Load 36.63 kg/sq.m.

Engine Limbach 1700EA

Twin-Astir SE-TZL

Data:

Span 17.5 m./ 57.4 ft
Area 17.80 sq. m. / 191.6 sq.ft.
Aspect ratio 17.2
Airfoil Eppler E 603
Empty weight 368 kg. / 811 lb.
Payload 212kg. / 468 lb.
Gross weight 580 kg. / 1279 lb.
Wing loading 32.58 kg. / sq. m. / 6.67 lb. / sq. ft.
Structure GFRP and CFRP
Performance

L/D max. 35 105 kph /56 kt / 65 mph
Min. sink 0.75 m/s / 2.45 fps / 1.45 kt
80 kph / 43 kt / 49 mph

Twin II SE-UFZ

Data:

General characteristics

  • Crew: Two
  • Length: 8.18 m
  • Wingspan: 17.50 m
  • Height: 1.55 m
  • Wing area: 17.8 m2
  • Aspect ratio: 17.1
  • Empty weight: 390 kg
  • Gross weight: 580 kg

Performance

  • Maximum speed: 250 km/h
  • Cruising speed: 85 km/h
  • G limits: +5.3/-2.65 at Va
  • Maximum glide ratio: ca. 36.5
  • Rate of sink: ca. 0.64 m/s

Källa: Wikipedia

Bergfalke II SE-SYT

Data:

Aspect ratio 15.6

Span 16.6 m

Area 17.9 sq.m

Empty Weight 275 kg

Payload 190 kg

Gross Weight 465 kg

Wing Load 25.98 kg/sq.m

Astir CS  SE-UGE

Data:

Span 15.0 m./ 49.2 ft
Area 12.40 sq. m. / 133,5 sq.ft.
Aspect ratio 18.2
Airfoil Eppler E 603
Empty weight 248 kg. / 547 lb.
Payload 132 kg. / 291 lb.
Gross weight 380 kg. / 838 lb.
Wing loading 30.64 kg. / sq. m. / 6.27 lb. / sq. ft.
Structure fiberglass
Performance

L/D max. 33.3 93 kph / 50 kt / 58 mph
Min. sink 0.70 m/s / 2.3 fps / 1.36 kt
76 kph / 41 kt / 46 mph

Discus CS SE-UPA

Data:

– Discus A, B, bT, BM, CS (WL)
Span 15.0 m./ 49.2 ft
Area 10.58 sq. m. / 113.9 sq.ft.
Aspect ratio 21.3
Empty weight 228 kg. / 503 lb.
Payload 297 kg. / 654 lb.
Water ballast 180 kg / 397 lb
Gross weight 525 kg. / 1,157 lb.
Wing loading 49.62 kg. / sq. m. / 10.16 lb. / sq. ft.
Engine (Discus bT) (15,3 kW / 20,5 bhp Solo 2350)
Engine (Discus BM) (35 kW/ 47 bhp Rotax 463)
Structure composite and steel tube
Performance

L/D max. 43 100 kph / 54 kt / 62 mph
Min. sink 0.59 m/s / 1.94 fps / 1.15 kt
78 kph / 42 kt / 49 mph

 Data från The Sailplane Directory om inte annat anges.
